328JET-ER
Length
21.284 m
Flat Wing Span
20.976 m
Height
7.234 m
Fuselage Diameter
2.41 m
Cabin Diameter
2.18 m
Flat Wing Area
40 m²
Wing Sweepback
7.1 °
Flat Wing Aspect Ratio
11
Max Seating
34
Cargo Volume
6.4 m³
Cruise Speed
0.61 km/h
Max Speed
0.66 km/h
Number of Engines
2
Aircraft Engine
Entry Into service
2000-04-01
Maximum Take-Off Weight
15.66 t (paragliders: kg)
Maximum Landing Weight
14.39 t (paragliders: kg)
Maximum Zero Fuel Weight
13.07 t (paragliders: kg)
Operational Empty Weight
9.42 t (paragliders: kg)
Maximum Payload
3.65 t (paragliders: kg)
Total Fuel Capacity
4558
Take Off Distance
1420 m
Pictures
Do328
| Name | Aircraft Engine | Length (m) | Flat Wing Span (m) | Max Seating | First Flight | Entry Into service |
|---|---|---|---|---|---|---|
| 328JET | PW306B | 21.23 | 20.98 | 34 | 1998-01-20 | 1999-08-09 |
| 328JET-ER | PW306B | 21.284 | 20.976 | 34 | 2000-04-01 |
Aircraft Weight Variants
| Aircraft | Maximum Take-Off Weight (t (paragliders: kg)) | Maximum Landing Weight (t (paragliders: kg)) | Maximum Zero Fuel Weight (t (paragliders: kg)) | Operational Empty Weight (t (paragliders: kg)) | Maximum Payload (t (paragliders: kg)) | Total Fuel Capacity | Maximum Range (km) |
|---|---|---|---|---|---|---|---|
| 328JET-ER | 15.66 | 14.39 | 13.07 | 9.42 | 3.65 | 4558 | |
| 328JET | 15.2 | 14.09 | 12.61 | 9.33 | 3.28 | 4558 | 2740 |
Similar airplanes
| Name | Aircraft Engine | Length (m) | Flat Wing Span (m) | Max Seating | |
|---|---|---|---|---|---|
| Dornier 328 | 21.28 | 20.98 | Compare | ||
| Howard 500 | 17.6784 | 21.336 | 14 | Compare | |
| Saab 340 AEW&C | General Electric T700 | 20.57 | 21.44 | Compare | |
| Mikoyan MiG-110 | TV7-117 | 18.5 | 22.12 | 49 | Compare |
| Blackburn B-20 | Rolls-Royce Vulture | 21.0312 | 24.9936 | Compare | |
| Bombardier Challenger 300 | 20.9184 | 19.2024 | 19 | Compare |
All data (27 fields)
- Name
- 328JET-ER
- Manufacturer
- Fairchild-Dornier
- Family
- Do328
- EASA TCDSN
- EASA.A.096
- Program Launch
- 1999-09-30
- Entry Into service
- 2000-04-01
- Launch Customer
- Atlantic Coast Jet
- Length (m)
- 21.284
- Height (m)
- 7.234
- Cockpit Crew
- 2
- Max Seating
- 34
- One Class Typical Seating
- 32
- Cargo Volume (m³)
- 6.4
- Max Speed (km/h)
- 0.66
- Cruise Speed (km/h)
- 0.61
- Flat Wing Span (m)
- 20.976
- Flat Wing Area (m²)
- 40
- Flat Wing Aspect Ratio
- 11
- Wing Sweepback (°)
- 7.1
- Fuselage Diameter (m)
- 2.41
- Cabin Diameter (m)
- 2.18
- Wake Category
- M
- Aircraft Engine
- PW306B
- Number of Engines
- 2
- Lateral Noise Level (EPNdB)
- 89.8
- Flyover Noise Level (EPNdB)
- 76.5
- Approac hNoise Level (EPNdB)
- 92.1
